| Brand Name : | Trixon |
| Model Number : | TSC-4802-XXDCR |
| Certification : | UL,TUV,FCC,CE,ROHS |
| Payment Terms : | L/C D/P |
| Price : | Negotiable |
| Delivery Time : | Negotiable |
| Supply Ability : | Negotiable |
This SFP Transceiver Module is an ideal choice for long-distance optical communication applications. It is compliant with MSA SFP Specification SFF-8472 and is powered by a single 3.3V power supply and TTL logic interface. It features a 1310nm CWDM laser and is capable of transmitting data with a distance of up to 2km over single-mode fiber (SMF). This transceiver module also supports DDMI (Digital Diagnostic Monitoring Interface) and a LC connector.
| Property | Details |
|---|---|
| Fiber Type | SMF |
| Data Rate | Operating Data Rate Up To 2.5 Gbps |
| Distance | 2km |
| Temperature Range | -5℃ ~+70℃ |
| Laser | CWDM |
| DDMI | YES |
| Product Name | OC-48/STM-16 SFP CWDM Transceiver |
| Power Supply | Single 3.3V Power Supply And TTL Logic Interface |
| Compliant | Compliant With MSA SFP Specification SFF-8472 |
| Connector Type | Duplex LC Connector Interface |
| 1.25G SFP | YES |
| 1310nm | YES |
| SFF-8472 | YES |
(2Km)
| Parameter | Symbol | Min | Typ. | Max | Unit | Note | ||
| Transmitter | ||||||||
| Centre Wavelength | λc | λc-7.5 | λc | λc+7.5 | nm | |||
| Spectral Width*Note4 | ∆λ | 1 | nm | DFB-LD | ||||
| Average Output Power | POUT | -10 | -3 | dBm | ||||
| Extinction Ratio | ER | 8.2 | dB | |||||
| Average Power of OFF Transmitter | POFF | -45 | dBm | |||||
| Output Optical Eye | Complies with STM-16/OC-48 eye masks when filtered | |||||||
| Receiver | ||||||||
| Centre Wavelength | λc | 1200 | 1600 | nm | ||||
| Sensitivity*Note5 | PIN | -18 | dBm | |||||
| Receiver Overload | Overload | -3 | dBm | |||||
| Optical Return Loss | 12 | dB | ||||||
| LOS Assert | LOSA | -35 | dBm | |||||
| LOS De-Assert | LOSD | -25 | dBm | |||||
| LOS Hysteresis | 0.5 | 4 | dB | |||||
The Trixon TSC-4802-XXDCR SFP Transceiver Module is an advanced and reliable product that provides high-speed and low-power data transmission. This module is compliant with MSA SFP specification SFF-8472 and can operate at data rates up to 2.5 Gbps. It is designed with a single mode laser and DDMI (Digital Diagnostic Monitoring Interface) that offers a maximum transmission distance of up to 2km. The module is equipped with a duplex LC connector interface, providing excellent transmission performance. This product is ideal for applications such as high-speed data transfer, Ethernet, Fibre Channel, and other fiber-optic transmission networks.
Data Rate: Transceiver modules can be customized to support different data rates based on the requirements of the network. Common data rates include 1Gbps, 10Gbps, 25Gbps, and higher.
Transmission Distance: The transmission distance of a transceiver module can be customized to meet specific network requirements. Depending on the technology used, modules can support short-reach (e.g., a few meters), medium-reach (e.g., up to 10 kilometers), or long-reach (e.g., up to 80 kilometers or more) applications.
Temperature Range: The temperature range of a transceiver module can be customized to ensure optimal performance in specific environmental conditions. This customization allows the module to operate reliably in temperature extremes, such as in industrial or outdoor environments.
Connector Interface: Transceiver modules can be customized to support different types of connector interfaces, such as LC, SC, or MPO connectors. The choice of connector interface depends on the specific network equipment and cabling infrastructure being used.
Protocols and Standards: Transceiver modules can be customized to support various protocols and standards, such as Ethernet, Fibre Channel, SONET/SDH, or specific industry standards.
Wavelengths: For modules using wavelength division multiplexing (WDM) technologies, customization options may include specific wavelength channels or combinations to support specific network architectures or requirements.
Form Factor: Transceiver modules come in various form factors, such as SFP, SFP+, QSFP, or CFP. Depending on the network equipment, customization may involve selecting the appropriate form factor for compatibility.
We offer comprehensive technical support and service for our SFP Transceiver Module. Our technical support staff is highly knowledgeable and experienced, and can provide you with assistance and advice throughout the lifetime of the product.
Our technical support team is available 24/7 to answer any questions you may have regarding installation, configuration, troubleshooting, and any other technical issues you may encounter. We also provide free software updates and product upgrades to ensure your product is always up to date.
We also offer a comprehensive warranty program that covers any defects or malfunctions of the product. This includes free repair and replacement services, as well as product refunds if applicable.
Our commitment to excellent customer service ensures that you get the most out of your SFP Transceiver Module. If you have any questions or issues, please do not hesitate to contact us.
Packaging and Shipping for SFP Transceiver Module:
The SFP Transceiver Module is packaged in an electrostatic
discharge (ESD) bag and shipped in a corrugated box. The box is
labeled with the product name, part number, and serial number. The
box is sealed with tape to ensure that the product is not exposed
to any environmental hazards during transportation.
Reference Datasheet File code: DS210006
|
|
